Centerless Pipe Polishing Machine Short Small Tube
- Technical Detail
- Centerless pipe polishing machine short small tube
- Model:WSPR-1-100
- Working capacity (min.and max.diameter):2-100mm
- Working capacity (min.and max.pipe length):1-3000mm
- Station no.:1
- Feeding speed: 1-6m/min(adjustable, stepless speed adjusting)
- Abrasive wheel speed: 2800rpm
- Abrasive wheel size:Dia250xthickness80mm,hole32mm
- Wheel motor:4kw
- Feeding motor:0.4kw
- Total power:4.4kw
- Consumption:9A
- Voltage:single-phase / 3-phase customized
- Standard with 1 set grinding wheel
- Gross weight:200kgs
- Dimension:950x950x1100mm (wooden case size)
Centerless pipe polishing machine short small tube is specially used for round pipe polishing machine. It adopts the principle of centerless grinding, which can grind the workpiece with a large margin or finely grind and polish the workpiece. According to the different materials and polishing requirements of the workpiece, the abrasive cloth wheel, hemp wheel, A variety of polishing tools such as cloth wheels and nylon wheels are used to polish the workpiece.It is suitable for grinding and polishing various metal outer surfaces of circular sections, hardware, electroplating, vehicle parts, machining, steel and wood furniture, standard parts, shafts, pipe fittings, and oil cylinders.
PRODUCT SPECIFICATION
- Centerless pipe polishing machine short small tube
- Model:WSPR-1-100
- Working capacity (min.and max.diameter):2-100mm
- Working capacity (min.and max.pipe length):1-3000mm
- Station no.:1
- Feeding speed: 1-6m/min(adjustable, stepless speed adjusting)
- Abrasive wheel speed: 2800rpm
- Abrasive wheel size:Dia250xthickness80mm,hole32mm
- Wheel motor:4kw
- Feeding motor:0.4kw
- Total power:4.4kw
- Consumption:9A
- Voltage:single-phase / 3-phase customized
- Standard with 1 set grinding wheel
- Gross weight:200kgs
- Dimension:950x950x1100mm (wooden case size)
| Content | Data | Content | Data | ||||
| Working capacity | 2-100mm diameter | Wheel motor | 4kw | ||||
| Working capacity | Length 1mm-3000mm | Feeding motor | 0.4kw | ||||
| Station no. | One Station | Voltage | single-phase / 3-phase | ||||
| Feeding speed | 0-6m/min(adjustable) | Gross weight | 200kgs | ||||
| Abrasive wheel speed | 2800rpm | Dimension | 950*950*1100mm |
APPLICATION
Pipe polishing machine are widely used in below applications.
- Small diameter minimum 2mm steel pipe polishing
- Big diameter maximum 100mm metal pipe polishing
- Steel bolt and rod polishing
- Steel soft hose polishing
FAQ
- Is this pipe polishing machine working for both pipe and solid rod?
- Yes, it works for both of them.
- What is the difference between single-station machine and multi-station polishing machine?
- Single-head machine means there is only single one polishing wheel while for multi-head machine there is several working position with different material of polishing
- What kind of grinding wheel do we use on our machine?
- We have nylon wheel, sand wheel, fiber wheel, cloth wheel and wire brush wheel for various applications.
- What is the life span of the abrasive wheel?
- 3500meters rodpolishing each.
- Do you have machine in stock?
- Yes, we have ready stock for regular machines, but if your voltage are different from what in China we will need 7-10days to customize motor for you.
