Pneumatic Pipe Polishing Machine

The pneumatic pipe polishing machine can be equipped with various polishing wheels to create different drawing effects, widely used in polishing of stainless steel, steel non-ferrous metals, plastic, and wood on the grinding, polishing, fine polishing.

PRODUCT SPECIFICATION

• Model no.: WSPR-1-100P
• The pneumatic type can polish a certain point of the workpieceand return the machine to the initial position after polishing
• Working capacity (min.and max.diameter) 3-100mm
• Working capacity (min.and max.pipe length) 1-3000mm
• Station no. 1
• Feeding speed  1-6m/min(adjustable, stepless speed adjusting)
• Abrasive wheel speed 2800rpm
• Abrasive wheel size Dia250xthickness80mm,hole32mm
• Wheel motor 4kw
• Feeding motor 0.4kw
• Total power 4.4kw
• Consumption 9A
• Voltage single-phase / 3-phase customized
• Standard with 1 set grinding wheel
• Gross weight 220kgs
• Dimension 950x950x1100 (wooden case size)

Hangzhou wise machinery co., ltd. offers a complete line of finishing equipment for tube and pipe processing. Designed to limit your downtime and minimize material waste, our equipment is customized to fit your specifications and integrate seamlessly within your production line. We prioritize operator safety and efficiency by offering both manual and automatic pipe tube feeding solutions. Contact us to find the full finishing system or single machine to fit your needs.
