Tube Polishing Machine 6 Head Stainless Steel Pipe Polishing

Tube polishing machine 6 head stainless steel pipe polishing – WSPR-6-160 – is the perfect choice for finishing the surface of round pipe and tubes.
It is simple to work with. You only have to insert the pipe manually and the guide wheel will push the pipe go forward in the meantime the grinding wheel will polish the pipe automatically.

PRODUCT SPECIFICATION

• Vertical type 6station pipe polishing machine
• Model no.: WSPR-6-160
• Working capacity (min.and max.diameter):8-160mm
• Working capacity (min.and max.pipe length):500mm to any
• Station no.:6
• Feeding speed:1-6m/min(adjustable, stepless speed adjusting)
• Abrasive wheel speed:2800rpm
• Abrasive wheel size:Dia250xthickness80mm,hole32mm
• Wheel motor:4kw * 6pieces
• Feeding motor:5kw
• Air blower motor:2kw * 2pieces
• Total power:30kw
• Consumption:60A
• Voltage:3-phase customized
• Standard with 1 set grinding wheel
• Gross weight:1500kgs
• Dimension:3700x1100x1200 (wooden case size)

The pipe polishing machine can be equipped with various polishing wheels to create different drawing effects, widely used in polishing of stainless steel, steel non-ferrous metals, plastic, and wood on the grinding, polishing, fine polishing.
